BUSEAL WRAP - VAPOUR BARRIER INSULATION (SHC 700-121)


Brand
:
SAMHWA CHEMICALS
Supplier
:
INSULREF SDN BHD
Email
:
sales@insulref.com
Phone
:
0126829356
Location
:
Selangor, Malaysia



High Quality BUSEAL Wrap - Vapour Barrier Malaysia



Our BUSEAL wrap is a self-adhesive, high quality, heavy duty vapour barrier and waterproof wrapping material made of vulcanised butyl rubber.

It is specially designed as a primary vapour barrier for cryogenic application which includes LNG liquefaction, storage tanks, facilities, building, and the HVAC industry. It features the perfect watertight and durability applied in HVAC joints. Ideal for insulation jackets, rest assured that our BUSEAL wrap - vapour barrier can reduce costs and delivery time thanks to zero shortage problem by domestic production.



Main Purposes :

  • Primary vapour barrier

  • Excellent resistance to vapour and UV

  • Easy to apply

  • Strong adhesion strength

  • Industrial cold and cryogenic application for LNG tank, pipe and other facilities

  • Commercial building and HVAC industry





Application :

Ensure that the surface is free of moisture, foreign material, grease, and other contaminants.

Cut the BUSEAL to your desired size, apply and press down firmly, you may use a roller for that matter. To avoid wrinkling, kindly release the liner slowly.

Before use, always ensure if BUSEAL is compatible with the substrates for adhesion and chemical reaction. Apply only on clean dry surfaces.



Extra Remarks :

Keep and apply between 40℉ (4℃) and 100℉ (38℃)



SHC 700-121 is a self-adhesive outer vapour barrier sheet composed of butyl rubber compound laminated to aluminium and tough Polyester film and a treated peel and stick release liner.



COLOR



ADHESION STRENGTH (ASTM D1000)

SHC 700-121: Aluminum-Black



≥  10 N/cm

SHC 700-122: Aluminum-Gray









ELONGATION (ASTM D1000)

COMPOSITION



≥  30%

Aluminium foil faced Butyl wrap





12㎛ PET+25㎛ AL+12㎛ PET+Butyl Rubber Compound   (Others available on requests)



TENSILE STRENGTH (ASTM D1000)





≥  60 N/cm

DENSITY





1.50 ± 0.05 g/㎤



BREAKING STRENGTH (ASTM D1000)





Over 80 N/10㎜

DIMENSION





Thickness: 1.2㎜ ±5%



REMARKS

Width: 1meter



Store and apply between 0℃ and 40℃.

Length: 15meter





(15㎡ Roll)



Contains no asbestos, lead, mercury or mercury compounds.







SERVICE TEMPERATURE LIMITS



BUSEAL® WRAP 12 is compatible with most kinds of substrates.

(Temperature at the coated surface)





- 40 ~ 121℃



BUSEAL® WRAP 12 should be applied on clean surfaces free from moisture, foreign materials, oil and any contaminations.







WATER VAPOR PERMEANCE (ASTM E 96)



Cut BUSEAL® WRAP 12 to size, apply and press down firmly, preferably with a roller.

< 0.02 metric perms









Be sure to remove release liner gradually to avoid wrinkling.

SURFACE BURNING CHARACTERISTICS (ASTM E84)  Class 1 or A
